All Tires
ATR12
Trailer
Next generation trailer tire for regional applications designed with a wide tread to reduce irregular wear, a tread compound to offer better fuel efficiency, solid shoulder ribs that improve wet braking, and innovative circum-ferential grooves for quicker water evacuation.
Category: Regional
Features
WIDE TREAD WITH INCREASED TREAD CONTACT AREA.
helps reduce irregular wear
SOLID SHOULDER RIBS.
enable efficient braking on dry & wet surfaces.
INNOVATIVE CIRCUMFERENTIAL GROOVE.
design offers quicker water evacuation while improving trailer stability.
Specifications
| Tire Size | Service Description | Load Range/Ply Rating | Rim Width (inches) | Max. Load Single (lbs) | Max. Load Dual (lbs) | Inflation Pressure (psi) | Overall Diameter (inches) | Section Width (inches) | Minimum Dual Spacing (inches) | Tread Depth (32nds) | Static Loaded Radius (inches) | Max Speed (mph) | Revs Per Mile |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 215/75R17.5 | 135/133J | H/16 | 6.00 | 4805 | 4540 | 125 | 30.2 | 8.3 | 9.4 | 15 | 14.0 | 62 | 694 |
| 235/75R17.5 | 143/141J | J/18 | 6.75 | 6010 | 5675 | 125 | 31.3 | 9.1 | 10.3 | 15 | 14.3 | 62 | 673 |
| 245/70R17.5 | 143/141J | J/18 | 7.50 | 6010 | 5675 | 130 | 30.9 | 9.8 | 11.0 | 15 | 14.3 | 62 | 679 |
| 265/70R19.5 | 143/141J | J/18 | 7.50 | 6010 | 5675 | 125 | 34.0 | 10.3 | 11.6 | 15 | 15.9 | 62 | 613 |
| 285/70R19.5 | 150/148J | J/18 | 8.25 | 7390 | 6940 | 130 | 35.1 | 11.0 | 12.5 | 15 | 16.2 | 62 | 597 |
