All Tires
ATH
Trailer
A premium trailer tire for long haul applications with uniquely designed shoulder grooves that provide resistance to uneven shoulder wear, shallow tread to reduce rolling resistance and heat buildup, and circumferential grooves for exceptional handling in wet conditions.
Category: Long Haul
EPA SmartWay® Verified
Features
LOW ROLLING RESISTANCE.
Shallow tread significantly reduces rolling resistance and offers good resistance to heat buildup and scrubbing.
EVEN SHOULDER WEAR.
Uniquely designed shoulder grooves provide outstanding resistance to uneven shoulder wear.
EXCEPTIONAL WET HANDLING.
Four circumferential grooves evacuate water quickly and deliver exceptional handling.
Specifications
| Tire Size | Service Description | Load Range/Ply Rating | Rim Width (inches) | Max. Load Single (lbs) | Max. Load Dual (lbs) | Inflation Pressure (psi) | Overall Diameter (inches) | Section Width (inches) | Minimum Dual Spacing (inches) | Tread Depth (32nds) | Static Loaded Radius (inches) | Max Speed (mph) | Revs Per Mile |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 11R22.5 | 148/145L | H/16 | 8.25 | 6945 | 6395 | 125 | 40.9 | 11.1 | 12.5 | 13 | 19.2 | 75 | 508 |
| 295/75R22.5 | 144/141L | G/14 | 9.00 | 6175 | 5675 | 110 | 39.9 | 11.3 | 13.2 | 13 | 18.6 | 75 | 523 |
| 11R24.5 | 149/146M | H/16 | 8.25 | 7165 | 6615 | 120 | 43.0 | 11.3 | 12.5 | 13 | 20.1 | 81 | 484 |
| 285/75R24.5 | 144/141L | G/14 | 8.25 | 6175 | 5675 | 110 | 41.0 | 10.9 | 12.5 | 13 | 19.3 | 75 | 507 |
