ASR1+
A steer axle tire exclusively designed with ‘All Position’ capability for regional applications with square shoulders to combat irregular wear, enhance cornering, and deliver long mileage, remarkable road grip in both dry and wet conditions, and a special tread compound that provides extraordinary resistance against abrasion.
Category: Regional
FREE REPLACEMENT 12MO / 2/32NDS
8-YEAR WARRANTY PERIOD
CASING WARRANTY ‘TIL 3 RETREADS
Features
EXCELLENT ROAD GRIP.
Siping on the tread offers remarkable road grip in both dry and wet conditions.
ENHANCED CORNERING AND LONG MILEAGE.
Square shoulders combat irregular wear, enhancing cornering and delivering long mileage.
EXTRAORDINARY RESISTANCE.
A special tread compound offers extraordinary resistance against abrasion.
Specifications
| Tire Size | Service Description | Load Range/Ply Rating | Rim Width (inches) | Max. Load Single (lbs) | Max. Load Dual (lbs) | Inflation Pressure (psi) | Overall Diameter (inches) | Section Width (inches) | Minimum Dual Spacing (inches) | Tread Depth (32nds) | Static Loaded Radius (inches) | Max Speed (mph) | Revs Per Mile |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 12R22.5* | 152/148M | H/16 | 9.00 | 7825 | 6945 | 125 | 42.9 | 11.9 | 13.5 | 20 | 20.1 | 81 | 485 |
| 295/80R22.5* | 152/148M | H/16 | 9.00 | 7825 | 6945 | 125 | 41.3 | 11.6 | 13.2 | 20 | 19.4 | 81 | 504 |
| 315/80R22.5* | 156/150L | L/20 | 9.00 | 8820 | 7385 | 125 | 42.7 | 12.2 | 13.8 | 20 | 19.8 | 75 | 490 |
| *SUITABLE FOR RV | |||||||||||||
Regrooving Guidelines
| Casing Size | Regrooving Guidelines | Retreading Recommendations | ||
| Depth (32nds) | Width (32nds) | Buffing Radius | Tread Width (mm) | |
| 12R22.5 | 3 | 7-9 | 700 mm or 27.5 inches | 230 |
| 295/80R22.5 | 3 | 7-9 | 700 mm or 27.5 inches | 240 |
| 315/80R22.5 | 3 | 7-9 | 800 mm or 31.5 inches | 260 |
